Particle and Desiccant Breathers (Compact Design)

Complete range of STAUFF particle breathers in combination with desiccant breathers, silica gel breathers, dehumidifiers and air breather dryers in different sizes and versions. Compact and light-weight design. Shock- and impact-resistant polycarbonate plastic housing with integrated UV protection. Plastic housing with female BSP connection thread. Full serviceability: Replaceable 3µm air filter element covered by a glass-fibre reinforced Polyamide plastic screw-cap and replaceable desiccant material. Wide range of accessories and options.
Particle and Desiccant Breathers
Grid List

Filters / Sorting

Categories

Particle and Desiccant Breathers
0 Results
Grid List

Unfortunately, your search did not provide any results.

Please check your search term and adjust it if necessary. You may already find the information you are looking for under the Product Categories or Further Contents tabs just above this note.

Perhaps you are looking for the following information?
▪  Information about the STAUFF Product Range
▪  STAUFF Product Catalogues
▪  CAD Files for STAUFF Products
▪  Latest News from STAUFF
▪  Global STAUFF Locations
▪  Online Contact Form

Alternatively, you can also reach us via Live Chat.

STAUFF Online Page-Flip Catalogue

Navigate and search content, forward via email, print and download in PDF format

STAUFF Online Page-Flip Catalogue
Navigate and search content, forward via email, print, and download in PDF format
Open STAUFF Online Page-Flip Catalogue in New Tab

STAUFF Product Catalogue

Download entire STAUFF product catalogue in PDF format

PDF
en
Catalogue STAUFF Hydraulic Accessories
15,40 mb
PDF
de
Catalogue STAUFF Hydraulic Accessories
15,40 mb
View Further STAUFF Product Catalogues

Function

When a reservoir or gearbox breathes, air containing moisture is ingested into the system. Temperature fluctuations will cause this moisture to condense which can speed up the oxidation of the fluid and lead to damage in the system.

Using SDBL series Particle and Air Conditioner, the incoming air first passes through a coarse filter, then a dryer agent material and finally an Air Breather element to filter out any dirt particles in addition to the moisture.


Compact Design

The SDBL series from STAUFF is a compact and flexible design that are used, for example, in power pack and reservoir manufacturing.

Available in five different housing lengths between 117,5 mm and 322,5 mm and have a diameter of 70 mm, 99 mm or 129 mm depending on the selected length.

The UV-resistant one piece plastic housing is designed with a female BSP thread on the bottom. The Particle and Silica Breather can be installed with a adaptor.

Feature

  • Available in 5 different sizes
  • Diameter of 70 mm, 99 mm or 129 mm
  • One piece plastic housing
  • BSP Female connection thread on plastic housing
  • Available with optional, integrated check valves (Type SDBL-CV)
  • Replaceable Drying Agent
  • Replaceable Air Breather Element under the plastic cap, Micron rating of the Air Breather Element: 3 μm
  • Refill and Maintenance Kits available
  • Extensive range of accessories
  • Operating temperature range: -40°C ... +90 °C / -40 °F ... +194 °F

The optional spring-loaded check valves integrated in the housing isolate the dryer material outside the from the atmosphere and optimising the service life.

A change in the color of the desiccant material indicates that it needs to be replaced (from red to orange in the standard version). Saturated dryer agent material, as well as the Air Breather element, which is placed under the plastic cap, can beeasily replaced by the user if necessary. Corresponding refill and maintenance kits are available from STAUFF.
